Ultra 9 285K or Ryzen 7800X3D: Gaming Test Insights

1. Introduction

The Core Ultra 9 285K has officially been released, and many are eager to see how it compares in gaming performance to the Core i9-14900K, Ryzen 9 9950X, and Ryzen 7 9800X3D.

For the first comparison, an initial conclusion can be drawn: the Core Ultra 9 285K’s gaming performance is close to that of the Core i9-14900K (slightly lower), although its CPU utilization is notably higher, with a noticeable gap. Interested readers can find more details in the article titled “Core Ultra 9 285K vs. Core i9-14900K: Gaming Performance Comparison” on my homepage.

The second main competitor to watch is the Ryzen 7 9800X3D, though it hasn’t been released yet. Therefore, I’ve included the previous generation Ryzen 7 7800X3D in the tests for comparison.

If the Core Ultra 9 285K can easily outperform the Ryzen 7 7800X3D, it should also stand a chance against the Ryzen 7 9800X3D. Conversely, if the Core Ultra 9 285K struggles to outperform the Ryzen 7 7800X3D, showing equal or even lower gaming performance, then it likely won’t beat the Ryzen 7 9800X3D either, effectively disqualifying it in advance.

Thus, the Core Ultra 9 285K vs. Ryzen 7 7800X3D matchup is a critical test, and this article will reveal the final results.

2. Specification Comparison

The Core Ultra 9 285K, released on October 24, 2024, uses TSMC’s 3nm process and features 8 large cores and 16 small cores, totaling 24 cores and 24 threads. It has a base clock speed of 3.7GHz, a maximum clock speed of 5.7GHz, an L2 cache of 40MB, and a smart cache of 36MB. The standard power consumption is 125W, with a peak of 253W, and the official suggested retail price is $589.

The Ryzen 7 7800X3D, released on January 4, 2023, utilizes TSMC’s 5nm process with 8 cores and 16 threads, featuring 512KB of L1 cache, 8MB of L2 cache, and 96MB of L3 cache. It has a base clock speed of 4.2 GHz and a maximum of 5.0 GHz, with a power consumption of 105W. It integrates two display cores running at 2200MHz, with a suggested retail price of $449.

3. Test Platform Configuration

The main configuration is as follows:

The Core Ultra 9 285K is paired with the MSI MAG Z890 TOMAHAWK motherboard, while the Ryzen 7 7800X3D is paired with the MSI MPG X670E CARBON motherboard. The remaining components are identical for both setups.

Memory: 32GB DDR5 6000MHz, GPU: GeForce RTX 4090, Storage: two Samsung 970 EVO 1TB drives, Operating System: Windows 11.

4. Gaming Test Between Ultra 9 285K and Ryzen 7800X3D

Seven games were tested at 1080P with the highest graphics settings. The following are detailed comparisons between the Ryzen 7 7800X3D (left) and the Core Ultra 9 285K (right) platforms.

Game 1: Ghostwire: Tokyo

• Ryzen 7 7800X3D: Avg FPS 183, min FPS 134, frame time 5.1ms, CPU usage 24%, power 56W, temp 52°C, RAM 10.8GB, GPU usage 84%, VRAM 6.4GB, GPU power 233W, GPU temp 47°C.
• Core Ultra 9 285K: Avg FPS 168, min FPS 132, frame time 5.3ms, CPU usage 19%, power 64W, temp 49°C, RAM 11.7GB, GPU usage 81%, VRAM 7.0GB, GPU power 229W, GPU temp 42°C.

The Core Ultra 9 285K showed a 15 FPS lower average, slightly less stable minimum FPS, and 8W higher power consumption, though with a 3°C lower temperature.

Game 2: Cyberpunk 2077

• Ryzen 7 7800X3D: Avg FPS 133, min FPS 82, frame time 7.0ms, CPU usage 67%, power 76W, temp 64°C, RAM 12.1GB, GPU usage 84%, VRAM 8.2GB, GPU power 253W, GPU temp 47°C.
• Core Ultra 9 285K: Avg FPS 128, min FPS 86, frame time 7.9ms, CPU usage 60%, power 112W, temp 58°C, RAM 10.3GB, GPU usage 80%, VRAM 8.4GB, GPU power 236W, GPU temp 42°C.

The Core Ultra 9 285K trailed by 5 FPS in average, though it had a higher minimum FPS. It consumed 36W more power but had a 6°C lower temperature.

Game 3: Red Dead Redemption 2

• Ryzen 7 7800X3D: Avg FPS 190, min FPS 149, frame time 4.9ms, CPU usage 51%, power 67W, temp 57°C, RAM 13.7GB, GPU usage 87%, VRAM 5.4GB, GPU power 281W, GPU temp 45°C.
• Core Ultra 9 285K: Avg FPS 178, min FPS 137, frame time 6.0ms, CPU usage 42%, power 92W, temp 52°C, RAM 10.8GB, GPU usage 85%, VRAM 5.0GB, GPU power 278W, GPU temp 44°C.

Here, the Core Ultra 9 285K’s average FPS was 12 FPS lower, with slightly increased frame time and 25W higher power usage, though it maintained a lower temperature by 5°C.

Game 4: The Witcher 3

• Ryzen 7 7800X3D: Avg FPS 103, min FPS 80, frame time 9.6ms, CPU usage 47%, power 66W, temp 58°C, RAM 12.2GB, GPU usage 88%, VRAM 7.3GB, GPU power 268W, GPU temp 43°C.
• Core Ultra 9 285K: Avg FPS 97, min FPS 49, frame time 9.6ms, CPU usage 44%, power 89W, temp 52°C, RAM 12.7GB, GPU usage 80%, VRAM 7.9GB, GPU power 259W, GPU temp 40°C.

The Core Ultra 9 285K performed 6 FPS lower in average, with a significantly lower minimum FPS. It used 23W more power but maintained a 6°C lower temperature.

Game 5: Microsoft Flight Simulator

• Ryzen 7 7800X3D: Avg FPS 94, min FPS 69, frame time 10.6ms, CPU usage 31%, power 57W, temp 62°C, RAM 13.1GB, GPU usage 50%, VRAM 6.7GB, GPU power 188W, GPU temp 45°C.
• Core Ultra 9 285K: Avg FPS 76, min FPS 64, frame time 13.1ms, CPU usage 21%, power 57W, temp 46°C, RAM 12.5GB, GPU usage 40%, VRAM 7.1GB, GPU power 110W, GPU temp 32°C.

The Core Ultra 9 285K showed a significant FPS drop (18 FPS lower), with higher frame time and identical power consumption, though with a 16°C cooler operating temperature.

Game 6: Hogwarts Legacy

• Ryzen 7 7800X3D: Avg FPS 89, min FPS 73, frame time 13.0ms, CPU usage 32%, power 59W, temp 60°C, RAM 21.1GB, GPU usage 56%, VRAM 10.4GB, GPU power 189W, GPU temp 45°C.
• Core Ultra 9 285K: Avg FPS 79, min FPS 67, frame time 12.4ms, CPU usage 27%, power 73W, temp 50°C, RAM 19.6GB, GPU usage 60%, VRAM 10.1GB, GPU power 220W, GPU temp 40°C.

In this game, the Core Ultra 9 285K was 10 FPS lower on average, with equal frame times and 14W higher power usage, while operating at a lower temperature by 10°C.

Game 7: Starfield

• Ryzen 7 7800X3D: Avg FPS 146, min FPS 99, frame time 6.2ms, CPU usage 79%, power 82W, temp 68°C, RAM 14.6GB, GPU usage 85%, VRAM 6.5GB, GPU power 255W, GPU temp 48°C.
• Core Ultra 9 285K: Avg FPS 151, min FPS 92, frame time 7.3ms, CPU usage 72%, power 129W, temp 64°C, RAM 11.9GB, GPU usage 89%, VRAM 6.2GB, GPU power 271W, GPU temp 44°C.

In Starfield, the Core Ultra 9 285K performed slightly better by 5 FPS on average, with higher power usage by 47W and a 4°C lower temperature.

5. Conclusion

The overall comparison is clear:

The Ryzen 7 7800X3D consistently exhibits higher CPU utilization, maximizing memory and GPU resources more effectively, showcasing a well-rounded hardware performance advantage, making it evidently better suited as a gaming processor.

In summary, the gaming performance of the Core Ultra 9 285K falls short of the Ryzen 7 7800X3D, effectively ruling it out from competing with the upcoming Ryzen 7 9800X3D and eliminating it from contention for the title of “strongest gaming processor.”

However, it is worth noting that compared to previous generations, the Core Ultra 9 285K demonstrates significant improvements in power consumption and temperature control, which is certainly commendable.
