RTX 3060 vs 5060: Game Performance Compared

01

Preface

According to previous performance evaluations, thanks to its new architecture, new manufacturing process, and GDDR7 memory, the GeForce RTX 5060 offers a significant performance improvement of approximately 23% compared to the previous generation GeForce RTX 4060.

This article will share a gaming performance comparison between the GeForce RTX 5060 and the two previous generations of products, specifically the GeForce RTX 3060, to assess the performance gap between the two, serving as a reference for interested readers.

02

Specifications Comparison

The GeForce RTX 5060 was released on May 19, 2025, using the GB206 GPU based on the Blackwell architecture and TSMC’s 4nm process. It features 3840 CUDA cores, 120 texture units, 48 raster units, 30 streaming multiprocessors, 120 tensor cores, 30 ray tracing units, and 32MB of L2 cache.

Its base clock is 2280 MHz, with a boost clock of up to 2497 MHz. It comes with 8GB of GDDR7 memory, a memory speed of 28 Gbps, a memory bus width of 128-bit, a memory bandwidth of 448.0 GB/s, FP32 performance of 19.18 TFLOPS, a power consumption of 145W, and a suggested retail price of $299.

The GeForce RTX 3060 was released on January 12, 2021, using the GA106 GPU based on the Ampere architecture and Samsung’s 8nm process. It features 3584 CUDA cores, 112 texture units, 48 raster units, 28 ray tracing units, 28 streaming multiprocessors, 112 tensor cores, and 3MB of L2 cache.

Its base clock is 1320 MHz, with a boost clock of up to 1777 MHz. It comes with 12GB of GDDR6 memory, a memory speed of 15 Gbps, a memory bus width of 192-bit, a memory bandwidth of 360 GB/s, FP32 performance of 12.7 TFLOPS, a power consumption of 170W, and a suggested retail price of $299.

03

Test Platform Configuration

The main configuration is as follows:

Processor: Core i5-12400F
Motherboard: MSI B760M Bomber WiFi
Memory: 32GB DDR5-6000
Graphics Cards: GeForce RTX 3060 and GeForce RTX 5060
Storage: Two Crucial P3 Plus 2TB SSDs

04

Game Testing (RTX 3060 vs 5060)

Seven games were tested at 1080P resolution. In the comparison images, the left side represents the GeForce RTX 3060 platform, and the right side represents the GeForce RTX 5060 platform.

1st Game: God of War

RTX 3060: Avg FPS 82, Min FPS 72, Frame Time 11.7ms, CPU Usage 28%, Temp 42°C, RAM 13.9GB, GPU Usage 99%, VRAM 5.3GB, Power 170W, GPU Temp 66°C
RTX 5060: Avg FPS 127, Min FPS 107, Frame Time 7.9ms, CPU Usage 36%, Temp 50°C, RAM 13.9GB, GPU Usage 98%, VRAM 5.3GB, Power 143W, GPU Temp 63°C

CPU usage higher by 8%, power 27W lower, temp 3°C lower. Avg FPS higher by 45 (≈55%), Min FPS higher by 35, frame time 4ms lower.

2nd Game: Ghostwire: Tokyo

RTX 3060: Avg FPS 60, Min FPS 53, Frame Time 17.2ms, CPU Usage 32%, Temp 45°C, RAM 13.2GB, GPU Usage 98%, VRAM 5.1GB, Power 170W, GPU Temp 66°C
RTX 5060: Avg FPS 84, Min FPS 73, Frame Time 13.2ms, CPU Usage 38%, Temp 47°C, RAM 13.4GB, GPU Usage 98%, VRAM 5.3GB, Power 143W, GPU Temp 62°C

CPU usage higher by 6%, RAM higher by 0.2GB, power 27W lower, temp 4°C lower. Avg FPS higher by 24 (≈40%), Min FPS higher by 20, frame time 4ms lower.

3rd Game: Cyberpunk 2077

RTX 3060: Avg FPS 65, Min FPS 52, Frame Time 14.4ms, CPU Usage 39%, Temp 54°C, RAM 11.4GB, GPU Usage 98%, VRAM 6.0GB, Power 168W, GPU Temp 63°C
RTX 5060: Avg FPS 92, Min FPS 73, Frame Time 9.4ms, CPU Usage 52%, Temp 54°C, RAM 11.6GB, GPU Usage 97%, VRAM 6.3GB, Power 144W, GPU Temp 60°C

CPU usage higher by 13%, RAM higher by 0.2GB, power 24W lower, temp 3°C lower. Avg FPS higher by 27 (≈42%), Min FPS higher by 21, frame time 5ms lower.

4th Game: Silent Hill 2

RTX 3060: Avg FPS 33, Min FPS 29, Frame Time 31.8ms, CPU Usage 19%, Temp 43°C, RAM 12.1GB, GPU Usage 98%, VRAM 6.5GB, Power 163W, GPU Temp 67°C
RTX 5060: Avg FPS 52, Min FPS 47, Frame Time 19.4ms, CPU Usage 25%, Temp 43°C, RAM 12.1GB, GPU Usage 98%, VRAM 6.5GB, Power 144W, GPU Temp 63°C

CPU usage higher by 6%, power 19W lower, temp 4°C lower. Avg FPS higher by 19 (≈58%), Min FPS higher by 18, frame time 11ms lower. RTX 3060 cannot run smoothly.

5th Game: Hogwarts Legacy

RTX 3060: Avg FPS 57, Min FPS 41, Frame Time 16.1ms, CPU Usage 31%, Temp 46°C, RAM 19.4GB, GPU Usage 99%, VRAM 6.1GB, Power 169W, GPU Temp 66°C
RTX 5060: Avg FPS 74, Min FPS 53, Frame Time 13.2ms, CPU Usage 34%, Temp 48°C, RAM 20.4GB, GPU Usage 98%, VRAM 6.4GB, Power 144W, GPU Temp 61°C

CPU usage higher by 3%, RAM higher by 1GB, power 25W lower, temp 5°C lower. Avg FPS higher by 17 (≈30%), Min FPS higher by 12, frame time 3ms lower.

6th Game: Black Myth: Wukong

RTX 3060: Avg FPS 42, Min FPS 36, Frame Time 21.2ms, CPU Usage 27%, Temp 47°C, RAM 16.6GB, GPU Usage 99%, VRAM 6.0GB, Power 170W, GPU Temp 61°C
RTX 5060: Avg FPS 64, Min FPS 51, Frame Time 14.6ms, CPU Usage 32%, Temp 53°C, RAM 15.0GB, GPU Usage 98%, VRAM 5.9GB, Power 144W, GPU Temp 55°C

CPU usage higher by 5%, RAM lower by 1.6GB, power 26W lower, temp 6°C lower. Avg FPS higher by 22 (≈52%), Min FPS higher by 15, frame time 7ms lower.

7th Game: The Last of Us Part II

RTX 3060: Avg FPS 61, Min FPS 45, Frame Time 15.6ms, CPU Usage 62%, Temp 45°C, RAM 14.6GB, GPU Usage 98%, VRAM 8.2GB, Power 145W, GPU Temp 58°C
RTX 5060: Avg FPS 87, Min FPS 63, Frame Time 10.4ms, CPU Usage 74%, Temp 57°C, RAM 14.5GB, GPU Usage 98%, VRAM 7.4GB, Power 122W, GPU Temp 55°C

CPU usage higher by 12%, VRAM lower by 0.8GB, power 23W lower, temp 3°C lower. Avg FPS higher by 26 (≈43%), Min FPS higher by 18, frame time 5ms lower.

05

Comparison Conclusion

Overall, compared to the GeForce RTX 3060, the GeForce RTX 5060 offers a significant overall advantage—not only in performance but also in power consumption and temperature efficiency.

Based on the comprehensive test results above, the GeForce RTX 5060 outperforms the GeForce RTX 3060 by approximately 46% in overall performance. This is the final conclusion of this article and is provided for reference only. Under such circumstances, the GeForce RTX 3060 is no longer worth considering.
