Optimizing the stack-up structure of high-layer-count PCBs is a key step in enhancing overall performance. The following explains the optimization strategies and cases based on four core objectives: signal integrity, power integrity, electromagnetic compatibility, and thermal performance.
I. Signal Integrity Optimization
- Tight Coupling Between Signal Layers and Reference Planes
- Strategy: Place high-speed signal layers (e.g., differential pairs, single-ended signals) adjacent to reference planes (GND or PWR) to minimize return path length, reduce crosstalk and radiation.
- Case:
- Typical 8-layer stack-up: TOP-GND-SIG1-PWR-SIG2-GND-SIG3-BOTTOM, where SIG1 and SIG2 are high-speed signal layers referenced by GND and PWR respectively.
- If a signal layer is more than one layer away from a reference plane (e.g., SIG1 separated from GND by PWR), increase decoupling capacitor density.
- Symmetry in Differential Pair Routing
- Strategy: Differential pairs must be routed on the same signal layer with equal length, width, and spacing, with continuous reference planes.
- Optimization: Assign independent signal layers for differential pairs in the stack-up to avoid crossover with other signals.
- Avoid Signal Crossovers Over Plane Splits
- Strategy: Signal layers must avoid crossing split regions of power or ground planes. If unavoidable, use 0Ω resistors or ferrite beads to bridge.
- Example: If PWR layer is split into 3V and 1.8V regions, high-speed signals should not cross the split line.
II. Power Integrity Optimization
- Paired Configuration of Power and Ground Planes
- Strategy: Each power plane (PWR) should be adjacent to a ground plane (GND) to form a low-impedance return loop.
- Case:
- 10-layer stack-up: TOP-GND-SIG1-PWR1-GND-PWR2-SIG2-GND-SIG3-BOTTOM, with PWR1 and PWR2 paired with GND to reduce power noise.
- Placement of Decoupling Capacitors
- Strategy: Place decoupling capacitors near the power entry and chip power pins; keep the path from capacitor pins to power/ground planes as short as possible.
- Optimization: Reserve adjacent PWR and GND layers in the stack-up for easy connection between capacitor pads and planes.
- Management of Power Plane Splitting
- Strategy: If power plane splitting is necessary, split lines should be perpendicular to signal traces to avoid parallel routing.
- Example: When PWR layer is split into 5V and 12V, split lines should be perpendicular to signal trace direction.
III. Electromagnetic Compatibility Optimization
- Shielding Layer Design
- Strategy: Add complete ground planes outside sensitive signal layers (e.g., clock, RF) to form a Faraday cage effect.
- Case:
- 12-layer stack-up: TOP-GND-SIG1-PWR1-GND-SIG2-PWR2-GND-SIG3-PWR3-GND-BOTTOM, where SIG2 is a sensitive signal layer with GND planes on both sides.
- Reduction of Interlayer Coupling
- Strategy: Isolate high-speed signal layers from low-speed signal layers using ground planes to prevent crosstalk.
- Optimization: Alternate signal and reference planes in the stack-up, e.g., SIG-GND-SIG-PWR.
- Control of Interlayer Dielectric Thickness
- Strategy: Reduce dielectric thickness between signal and reference planes (e.g., using thin core boards) to lower characteristic impedance and reduce radiation.
- Example: Reducing dielectric thickness from 2mm to 0.1mm can lower characteristic impedance by about 5Ω.
IV. Thermal Performance Optimization
- Increase Inner Layer Copper Thickness
- Strategy: Increase copper thickness (e.g., 2oz) in inner layers of high-power areas (e.g., power modules, processors) to improve heat dissipation.
- Optimization: Allocate continuous copper layers to high-power areas in the stack-up and connect them to ground planes.
- Thermal Via Design
- Strategy: Place thermal via arrays below heat-generating components to transfer heat to inner copper layers or backside heat sinks.
- Example: Thermal via diameter 3mm, spacing 1.0mm; density determined by power consumption.
- Thermal Layer Configuration
- Strategy: Add independent thermal layers (e.g., copper foil layers) in the stack-up, connected to the enclosure with thermal interface material.
- Case: 14-layer stack-up: TOP-GND-SIG1-PWR1-GND-HEAT-PWR2-GND-SIG2-PWR3-GND-SIG3-HEAT-BOTTOM, where HEAT layers are dedicated for thermal dissipation.
V. Stack-Up Optimization Case Studies
| Layer Count | Typical Stackup Structure | Optimization Goals |
|---|---|---|
| 8 Layers | TOP–GND–SIG1–PWR–SIG2–GND–SIG3–BOTTOM | High-speed signal integrity, power integrity |
| 10 Layers | TOP–GND–SIG1–PWR1–GND–PWR2–SIG2–GND–SIG3–BOTTOM | Differential pair routing, power noise suppression |
| 12 Layers | TOP–GND–SIG1–PWR1–GND–SIG2–PWR2–GND–SIG3–PWR3–GND–BOTTOM | Electromagnetic shielding, multiple power domain isolation |
| 14 Layers | TOP–GND–SIG1–PWR1–GND–HEAT–PWR2–GND–SIG2–PWR3–GND–SIG3–HEAT–BOTTOM | High thermal demand, signal integrity |
VI. Summary
- Signal Integrity: Prioritize tight coupling between signal layers and reference planes; ensure symmetrical differential pair routing.
- Power Integrity: Pair power and ground planes, manage plane splitting, and add decoupling capacitors.
- EMC: Use shielding layers and interlayer isolation to reduce radiation; control dielectric thickness.
- Thermal Performance: Increase copper thickness, design thermal vias, and configure thermal layers.
By applying the above strategies, the performance of high-layer-count PCBs can be significantly improved to meet the demands of high speed, high density, and high reliability.
